Model DMW 130 Wheel 400
TECHNICAL DATA
VIDEO
FOTOS
Measure:
- Recommended excavator weight18 – 35 t 40,000 – 77,000 lb
- Rated power130 kW 175 (130) hp (kW)
- Cutting width (A)80 | 130 | 200 mm 3 | 5 | 8 in
- Cutting depth (B)400 mm 16 in
- Cutting depth with sliding device300 mm 12 in
- Cutter wheel diameter1.210 mm 48 in
- Torque at 350 bar21.000 Nm 15,500 lbf·ft
- Cutting force at 350 bar34.711 N 7,900 lbf
- Recomm. oil flow according to wheel diameter230 – 300 l/min 61 – 79 gal/min
- Max. oil flow at 50 bar340 l/min 90 gal/min
- Max. operating hydraulic pressure380 bar 5,500 (380) psi (bar)
- Max. rebar diameter in re-enforced concrete *20 mm 0.75 in
- Max. uniaxial compressive strength100 MPa 14,500 (100) psi (MPa)
- Weight of drive unit, approx.1.150 kg 2,500 lb
- Weight of cutter wheel, approx. **400 kg 880 lb
- Weight of dipping device, approx.300 kg 670 lb
- Weight of protection cover, approx.55 kg 130 lb
- Pick boxPH 32 HD Type PH 32 HD Type
- Standard pickER 17/75/70/30 Q ER 17/75/70/30 Q
KEMROC can supply wheels to order for various cutting widths and depths. Within technical boundaries, cutter wheels can be made to order.
* To maintain the warranty, check with the manufacturer before use in re-enforced concrete containing larger diameter rebar.
** Cutter wheel weight depends on diameter and width.
