DMW Cutter Wheels

Model DMW 130

TECHNICAL DATA

FOTOS

Measure:

Recommended excavator weight
18 – 35 t 40,000 – 77,000 lb
Rated power
130 kW 175 hp (130 kW)
Cutting width (A)
80 | 130 | 200 mm 3 | 5 | 8 in
Cutting depth (B)
400 mm 16 in
Cutting depth with sliding device
300 mm 12 in
Cutter wheel diameter
1.210 mm 48 in
Torque at 350 bar
21.000 Nm 15,500 lbf·ft
Cutting force at 350 bar
34.711 kN 7,900 lbf
Recomm. oil flow according to wheel diameter
230 – 300 l/min 61 – 79 gal/min
Max. oil flow at 50 bar
340 l/min 90 gal/min
Max. operating hydraulic pressure
380 bar 5,500 psi (380 bar)
Max. rebar diameter in re-enforced concrete *
20 mm 0.75 in
Max. uniaxial compressive strength
100 MPa 14,500 psi (100 MPa)
Weight of drive unit, approx.
1.150 kg 2,500 lb
Weight of cutter wheel, approx. **
400 kg 880 lb
Weight of dipping device, approx.
300 kg 670 lb
Weight of protection cover, approx.
55 kg 130 lb
Pick box
PH 32 HD Type PH 32 HD Type
Standard pick
ER 17/75/70/30 Q ER 17/75/70/30 Q

KEMROC can supply wheels to order for various cutting widths and depths. Within technical boundaries, cutter wheels can be made to order.

* To maintain the warranty, check with the manufacturer before use in re-enforced concrete containing larger diameter rebar.

** Cutter wheel weight depends on diameter and width.
