Model DMW 400 Wheel 1000
TECHNICAL DATA
FOTOS
Measure:
- Recommended excavator weight50 – 70 | 70 – 120 t 110k – 154k | 154k – 264k lb
- Rated power400 kW 536 hp (400 kW)
- Cutting width (B)130 | 200 | 400 mm 5 | 8 | 16 in
- Cutter length (A)1000 mm 40 in
- Cutting depth with sliding device900 mm 36 in
- Cutting wheel diameter (C)2700 mm 106 in
- Recommended rpm25 rpm 25 rpm
- Recomm. oil flow according to wheel diameter600 – 900 l/min 160 – 240 gal/min
- Max. oil flow at 50 bar1000 l/min 264 gal/min
- Max. operating pressure400 bar 5800 psi (380 bar)
- Torque at 380 bar142730 Nm 105272 lbf·ft
- Cutting force at 380 bar105.7 kN 23760 lbf
- Max. rebar diameter in re-enforced concrete *30 mm 1.25 in
- Max. rock compressive strength140 MPa 20000 psi (100 MPa) psi
- Weight of drive unit, approx.5500 kg 12130 lb
- Weight of cutter wheel, approx. **3300 kg 7280 lb
- Weight of dipping device, approx.1450 kg 3200 lb
- Weight of cutting wheel250 kg 550 lb
- Pick boxPH 32 HD Type PH 32 HD Type
- Standard pickER 22/75/70/30 Q ER 22/75/70/30 Q
KEMROC can supply wheels to order for various cutting widths and depths. Within technical boundaries, cutter wheels can be made to order.
* To maintain the warranty, check with the manufacturer before use in re-enforced concrete containing larger diameter rebar.
** Cutter wheel weight depends on diameter and width.
Model DMW 400 Wheel 1000
TECHNICAL DATA
VIDEO
FOTOS
Measure:
- Recommended excavator weight50–70 | 70–120 t 110,000 – 154,000 | 154,000 – 264,000 lb
- Rated power400 kW 535 hp (400 kW)
- Cutter depth (A)1.000 mm 39 inch
- Cutting width (B)130 | 200 | 400 mm 5 | 8 | 16 in
- Cutting wheel diameter (C)2700 mm 106 in
- Recommended rpm40 rpm 40 rpm
- Recommended oil flow900 l/min 238 gal/min
- Max. oil flow1200 l/min 317 gal/min
- Max. operating pressure400 bar 5,800 psi (380 bar)
- Torque at 380 bar142600 Nm 105,200 lbf·ft
- Cutting force at 380 bar106 kN 23,700 lbf
- Max. rock compressive strength140 MPa 20,305 psi (140 MPa) psi
- Weight of drive unit, approx.5500 kg 12,125 lb
- Weight of cutter wheel, approx. **1450 kg 3,197 lb
- Weight of dipping device, approx.250 kg 551 lb
- Weight of cutting wheel3300 kg 7,275 lb
- Weight per cutting width10500 kg 23,149 lbs
- Pick boxPH 38HD Type PH 38HD Type
- Number of picks62 Pcs 62 Pcs
- Standard pick25/80/80/38 C 25/80/80/38 C
- Standard hole patternLB50 LB50
- Compatible rotation unit (KRM)– –
KEMROC can supply wheels to order for various cutting widths and depths. Within technical boundaries, cutter wheels can be made to order.
* To maintain the warranty, check with the manufacturer before use in re-enforced concrete containing larger diameter rebar.
** Cutter wheel weight depends on diameter and width.
