EBA Auger Drive Attachments

Model EBA 2300

TECHNICAL DATA

FOTOS

Measure:

Recommended excavator weight
18 – 35 t 40,000 – 75,000 lb
Rated power
110 kW 150
Cutter length (A)
500 mm 20 in
Cutting width (B)
990 mm 39 in
Recommended rpm
70 rpm 70 rpm
Recommended oil flow
150 – 320 l/min 40 – 85 gal/min
Max. oil flow
360 l/min 95 gal/min
Max. operating pressure
400 bar 5,800 psi (400 bar)
Torque at 380 bar
27200 Nm 20,050 lbf·ft
Cutting force at 380 bar
181.3 kN 40,760 lbf
Weight
360 kg 795 lb
Output drive connection
H 80 Type H 80 Type
Pick box
PH 22 Type PH 22 Type
Standard pick
22/46/38/22 H 22/46/38/22 H
Max. drill diameter
1200 mm 47 in
Min. drill diameter
300 mm 12 in
Max. drilling depth at max. drill diameter
8,000 mm 157 in
Max. drilling depth at min. drill diameter
5,000 mm 315 in
Max. rock compressive strength
50 MPa 7,300 psi
