Measure:
  • Recommended excavator weight
    18 – 30 t 40000 – 65000 lb
  • Rated power
    100 kW 135 hp (100 kW)
  • Drum cutter length (A)
    1970 mm 78 in
  • Cutting width (B)
    600 | 700 | 800 mm 24 | 28 | 32 in
  • Cutter drum diameter (C)
    800 mm 31 in
  • Recommended rpm
    65 rpm 65 rpm
  • Recommended oil flow
    200 l/min 53 gal/min
  • Max. oil flow
    260 l/min 69 gal/min
  • Max. operating pressure
    400 bar 5800 psi (400 bar)
  • Torque at 380 bar
    18900 Nm 11600 lbf·ft
  • Cutting force at 380 bar
    47 kN 8835 lbf
  • Max. rock compressive strength
    80 MPa 11600 psi (80 MPa)  psi
  • Weight
    2450 | 2510 | 2620 kg 5402 | 5534 | 5776 lb
  • Pick box
    PH 32 HD Type PH 32 HD Type
  • Number of picks in cutter drums
    28 | 40 | 48 Pcs 28 | 40 | 48 Pcs
  • Number of picks in the cutter chain
    54 Pcs 54 Pcs
  • Standard pick
    17/75/70/30 Q  17/75/70/30 Q
  • Standard hole pattern
    LB30  LB30
  • Compatible rotation unit (KRM)
    KRM50  KRM50
