Measure:
- Recommended excavator weight18 – 30 t 40,000 – 65,000 lb
- Rated power100 kW 135 hp (100 kW)
- Drum cutter length (A)1.970 mm 78 in
- Cutting width (B)600 | 700 | 800 mm 24 | 28 | 32 in
- Cutter drum diameter (C)800 mm 31 in
- Recommended rpm65 rpm 65 rpm
- Recommended oil flow200 l/min 53 gal/min
- Max. oil flow260 l/min 69 gal/min
- Max. operating pressure400 bar 5,800 psi (400 bar)
- Torque at 380 bar15,700 Nm 11,600 lbf·ft
- Cutting force at 380 bar39 kN 8,835 lbf
- Max. rock compressive strength80 MPa 11,600 psi (80 MPa) psi
- Weight2450 | 2510 | 2620 kg 5402 | 5534 | 5776 lb
- Pick boxPH 32 HD Type PH 32 HD Type
- Number of picks in cutter drums28 | 40 | 48 Pcs 28 | 40 | 48 Pcs
- Number of picks in the cutter chain54 Pcs 54 Pcs
- Standard pick17/75/70/30 Q 17/75/70/30 Q
- Standard hole patternLB30 LB30
- Compatible rotation unit (KRM)KRM50 KRM50
