EK Chain Cutters

Model EK 100

TECHNICAL DATA
VIDEO
FOTOS
Measure:
  • Recommended excavator weight
    18 – 30 t 40,000 – 66,000 lb
  • Rated power
    100 kW 134 hp (100 kW)
  • Drum cutter length (A)
    1.970 mm 75 in
  • Cutter head width (B)
    600 | 700 | 800 mm 24 | 28 | 32 in
  • Cutter drum diameter (C)
    800 mm 32 in
  • Width of gearbox (D)
    565 mm 22 in
  • Recommended rotation speed
    70 rpm 65 rpm
  • Recommended oil flow
    180 – 240 l/min 50 – 55 gal/min
  • Max. oil flow
    260 l/min 69 gal/min
  • Max. operating hydraulic pressure
    400 bar 5,800 psi (400 bar)
  • Max. torque at max. hydraulic pressure
    19.080 Nm 13,500 lbf·ft
  • Max. cutting force at max. torque
    47,7  kN 10,300 lbf
  • Max. uniaxial compressive strength
    80 MPa 11,600 psi (80 MPa)
  • Weight
    2.450 | 2.510 | 2.620 kg 5,300 – 5,750 lb
  • Pick box
    PH 32 HD Type PH 32 HD Type
  • Number of picks in cutter drums
    28 | 40 | 48 Pcs 28 | 40 | 48 Pcs
  • Number of picks in the cutter chain
    54 Pcs 54 Pcs
  • Standard pick
    ER 17/75/70/30 Q  ER 17/75/70/30 Q
