TECHNICAL DATA
VIDEO
FOTOS
Measure:
  • Recommended excavator weight
    30 – 45 t 65000 – 100000 lb
  • Rated power
    140 kW 190 hp (140 kW)
  • Drum cutter length (A)
    2150 mm 85 in
  • Cutting width (B)
    800 | 900 | 1.000 mm 32 | 36 | 40 in
  • Cutter drum diameter (C)
    850 mm 33 in
  • Recommended rpm
    70 rpm 70 rpm
  • Recommended oil flow
    275 l/min 73 gal/min
  • Max. oil flow
    320 l/min 85 gal/min
  • Max. operating pressure
    400 bar 5800 psi (400 bar)
  • Torque at 380 bar
    25400 Nm 18750 lbf·ft
  • Cutting force at 380 bar
    60 kN 13420 lbf
  • Max. rock compressive strength
    100 MPa 14500 psi (100 MPa)  psi
  • Weight
    3650 | 3700 | 3800 kg 8046 | 8158 | 8378 lb
  • Pick box
    PH 32 HD Type PH 32 HD Type
  • Number of picks in cutter drums
    44 | 48 | 56 Pcs 44 | 48 | 56 Pcs
  • Number of picks in the cutter chain
    63 Pcs 63 Pcs
  • Standard pick
    17/75/70/30 Q  17/75/70/30 Q
  • Standard hole pattern
    LB40  LB40
  • Compatible rotation unit (KRM)
    KRM60  KRM60
