Model EK 150
TECHNICAL DATA
VIDEO
FOTOS
Measure:
- Recommended excavator weight35 – 50 t 77,000 – 110,000 lb
- Rated power150 kW 200 hp (150 kW)
- Drum cutter length (A)2.150 mm 85 in
- Cutter head width (B)800 | 900 | 1.000 mm 32 | 35 | 40 in
- Cutter drum diameter (C)850 mm 34 in
- Width of gearbox (D)700 mm 28 in
- Recommended rotation speed60 rpm 60 rpm
- Recommended oil flow280 – 320 l/min 74 – 85 gal/min
- Max. oil flow450 l/min 118 gal/min
- Max. operating hydraulic pressure400 bar 5,800 psi (400 bar)
- Max. torque at max. hydraulic pressure31.300 Nm 22,350 lbf·ft
- Max. cutting force at max. torque71.3 kN 16,030 lbf
- Max. uniaxial compressive strength100 MPa 15,000 psi (100 MPa)
- Weight3.650 | 3.700 | 3.800 kg 8,050 | 8,160 | 8,380 lb
- Pick boxPH 32 HD Type PH 32 HD Type
- Number of picks in cutter drums44 | 48 | 56 Pcs 44 | 48 | 56 Pcs
- Number of picks in the cutter chain63 Pcs 63 Pcs
- Standard pickER 17/75/70/30 Q ER 19/75/70/30 Q
