EK Chain Cutters

Model EK 150

TECHNICAL DATA
VIDEO
FOTOS
Measure:
  • Recommended excavator weight
    35 – 50 t 77,000 – 110,000 lb
  • Rated power
    150 kW 200 hp (150 kW)
  • Drum cutter length (A)
    2.150 mm 85 in
  • Cutter head width (B)
    800 | 900 | 1.000 mm 32 | 35 | 40 in
  • Cutter drum diameter (C)
    850 mm 34 in
  • Width of gearbox (D)
    700 mm 28  in
  • Recommended rotation speed
    60 rpm 60 rpm
  • Recommended oil flow
    280 – 320 l/min 74 – 85 gal/min
  • Max. oil flow
    450 l/min 118 gal/min
  • Max. operating hydraulic pressure
    400 bar 5,800 psi (400 bar)
  • Max. torque at max. hydraulic pressure
    31,300 Nm 22,350 lbf·ft
  • Max. cutting force at max. torque
    71.3 kN 16,030 lbf
  • Max. uniaxial compressive strength
    100 MPa 15,000 psi (100 MPa)
  • Weight
    3.650 | 3.700 | 3.800  kg 8,050 | 8,160 | 8,380 lb
  • Pick box
    PH 32 HD Type PH 32 HD Type
  • Number of picks in cutter drums
    44 | 48 | 56 Pcs 44 | 48 | 56 Pcs
  • Number of picks in the cutter chain
    63 Pcs 63 Pcs
  • Standard pick
    ER 17/75/70/30 Q  ER 19/75/70/30 Q
