EK Chain Cutters

Model EK 60

TECHNICAL DATA
VIDEO
FOTOS
Measure:
  • Recommended excavator weight
    10 – 17 t 22,000 – 37,500 lb
  • Rated power
    60 kW 80 hp (60 kW)
  • Drum cutter length (A)
    1.600 mm 75 in
  • Cutter head width (B)
    500 | 600  mm 20 in
  • Cutter drum diameter (C)
    600 mm 32 in
  • Width of gearbox (D)
    455 mm 18 in
  • Recommended rotation speed
    80 rpm 65 rpm
  • Recommended oil flow
    130 – 160 l/min 26 – 33 gal/min
  • Max. oil flow
    220 l/min 58 gal/min
  • Max. operating hydraulic pressure
    400 bar 5,800 psi (400 bar)
  • Max. torque at max. hydraulic pressure
    11.448 Nm 8,200 lbf·ft
  • Max. cutting force at max. torque
    38,2 kN 6,200 lbf
  • Max. uniaxial compressive strength
    50 MPa 7,300 psi (50 MPa)
  • Weight
    1.250 | 1.300 kg 3,530 lb
  • Pick box
    PH 22 Type PH 22 Type
  • Number of picks in cutter drums
    40 | 60 Pcs 56 Pcs
  • Number of picks in the cutter chain
    53 Pcs 55 Pcs
  • Standard pick
    ER 15/46/38/22 C  ER 15/46/38/22 C
