ES Cutter Heads

Model ES 30 HD

TECHNICAL DATA

FOTOS

Measure:

Recommended excavator weight
5 – 10 t 11,000 – 22,000 lb
Rated power
30 kW 40 hp (30 kW)
Diameter of cutter drum (A)
520 mm 20 in
Width of cutter drum (B)
300 mm 12 in
Cutting depth
110 mm 4 in
Min. oil flow
60 l/min 16 gal/min
Max. oil flow
110 l/min 29 gal/min
Max. hydraulic pressure
380 l/min 5,500 psi (380 bar) psi (bar)
Torque at 350 bar
4,100 Nm 3,100 lbf·ft
Pick box
PH 20 Type PH 20 Type
Number of picks
35 Pcs 35 Pcs
Standard pick
ER 16/48/32/20 H ER 16/48/32/20 H
