ES Cutter Heads

Model ES 30 HD

TECHNICAL DATA

FOTOS

Measure:

Recommended excavator weight

5 – 10 t 10000 – 20000 lb
Rated power

30 kW 40 hp (30 kW)
Cutting wheel diameter (C)

520 mm 20 inch
Cutting width (B)

300 mm 12 in
Cutting depth

110 mm 4 in
Min. rpm

80 U/min 80 rpm
Min. oil flow

60 l/min 16 gal/min
Max. oil flow

110 l/min 29 gal/min
Max. operating pressure

400 bar 5800 psi (400 bar)
Torque at 380 bar

4400 Nm 3200 lbf·ft
Cutting force at 380 bar

17 kN 3800 lbf
Weigth of base drive

125 kg 276 lbs
Pick box

PH 20 Type PH 20 Type
Number of picks

35 Pcs 35 Pcs
Standard pick

16/48/32/20 H 16/48/32/20 H
Standard hole pattern

LB10 LB10
Compatible rotation unit (KRM)

KRM30 KRM30
