ES Cutter Heads

Model ES 60 HD

TECHNICAL DATA

VIDEO

FOTOS

Measure:

Recommended excavator weight
15 – 23 t 33,000 – 50,000 lb
Rated power
80 kW 107 hp (80 kW)
Diameter of cutter drum (A)
670 mm 26 in
Width of cutter drum (B)
600 mm 24 in
Cutting depth
190 mm 7 in
Min. oil flow
150 l/min 40 gal/min
Max. oil flow
210 l/min 55 gal/min
Max. hydraulic pressure
380 l/min 5,500 psi (380 bar) psi (bar)
Torque at 350 bar
11,700 Nm 8,700 lbf·ft
Pick box
PH 20 Type PH 20 Type
Number of picks
69 Pcs 69 Pcs
Standard pick
ER 16/48/32/20 H ER 16/48/32/20 H
