EX Patch Planers

Model EX 30 HD

TECHNICAL DATA

FOTOS

Measure:

Recommended excavator weight

5 – 10 t 10000 – 20000 lb
Rated power

30 kW 40 hp (30 kW)
Cutting depth, adjustable (A)

0 – 120 mm 0 – 5 in
Cutting width (B)

300 mm 12 in
Cutting wheel diameter (C)

525 mm 21 inch
Recommended rpm

110 rpm 110 rpm
Recommended oil flow at 100 bar

80 l/min 21 gal/min
Max. oil flow

105 l/min 28 gal/min
Max. operating pressure

380 bar 5510 psi (380 bar)
Torque at 350 bar

4100 Nm 3000 lbf.ft
Cutting force at 350 bar

15 KN 3400 lbf
Total weight

420 kg 926 lbs
Pick box

PH 20 Type PH 20 Type
Number of picks

35 Pcs 35 Pcs
Standard pick

16/48/32/20 H 16/48/32/20 H
Standard hole pattern

LB10 LB10
Compatible rotation unit (KRM)

KRM30 KRM30
