EX Patch Planers

Model EX 45 HD

TECHNICAL DATA
VIDEO
FOTOS
Measure:
  • Recommended excavator weight
    10 – 16 t 22,000 – 35,000 lb
  • Rated power
    65 kW 88 hp (65 kW)
  • Cutting width, standard (A)
    450 mm 18 in
  • Cutting depth, adjustable (B)
    0 – 150 mm 0 – 6 in
  • Recommended rotation speed
    70 – 110 rpm 70 – 110 rpm
  • Recommended oil flow at 100 bar
    110 – 170 l/min 29 – 44 gal/min
  • Min. oil flow
    100 l/min 27 gal/min
  • Max. oil flow
    180 l/min 48 gal/min
  • Max. operating hydraulic pressure
    380 bar 5,500 psi (380 bar)
  • Torque at 350 bar
    8.700 Nm 6,500 lbf·ft
  • Cutting force at 350 bar
    30 N 6,750 lbf
  • Operating weight
    730 kg 730 lb
  • Pick box
    PH 20 Type PH 20 Type
  • Number of picks
    49 Pcs 49 Pcs
  • Standard pick
    ER 16/48/32/20 H  ER 16/48/32/20 H
