EX Patch Planers

Model EX 60 HD

TECHNICAL DATA

VIDEO

FOTOS

Measure:

Recommended excavator weight

15 – 23 t 35000 – 50000 lb
Rated power

80 kW 105 hp (80 kW)
Cutting depth, adjustable (A)

0 – 190 mm 0 – 7 in
Cutting width (B)

600 mm 24 in
Cutting wheel diameter (C)

675 mm 27 inch
Recommended rpm

105 rpm 105 rpm
Recommended oil flow at 100 bar

175 l/min 46 gal/min
Max. oil flow

200 l/min 53 gal/min
Max. operating pressure

380 bar 5510 psi (380 bar)
Torque at 350 bar

9300 Nm 6900 lbf.ft
Cutting force at 350 bar

28 KN 6200 lbf
Total weight

1230 kg 2710 lbs
Pick box

PH 20 Type PH 20 Type
Number of picks

69 Pcs 69 Pcs
Standard pick

19/48/36/20 H 19/48/36/20 H
Standard hole pattern

LB20 LB20
Compatible rotation unit (KRM)

KRM30 KRM30
