KDS Diamond Saws

Model KDS 20

TECHNICAL DATA

VIDEO

FOTOS

Measure:

Recommended excavator weight

2 – 4 t 5000 – 10000 lb
Max. Rated power

23 KW 30 hp (23 kW) hp
Max. Cutting depth (A)

400 mm 16 inch
Cutting wheel diameter (C)

600 | 1000 mm 24 | 39 in
Max. Cutting wheel diameter (C)

1000 mm 39 inch
Max. rpm

1100 rpm 1,100 rpm
Recommended rpm

730 – 1000 rpm 730 – 1,000 rpm
Recommended oil flow

25 – 35 l/min 7-9 gal/min
Max. operating pressure

350 bar 5080 psi (350 bar)
Torque at 350 bar

200 Nm 100 lbf.ft
Weight of drive unit, approx.

105 kg 231 lb
Weight of protective cover

57 | 72 kg 126 | 159 lbs
Weight of cutting wheel

30 kg 66 lb
Total weight

192 | 207 kg 423 | 456 lbs
Standard hole pattern

LB10 LB10
Compatible rotation unit (KRM)

KRM20 KRM20
