KDS Diamond Saws

Model KDS 50

TECHNICAL DATA

VIDEO

FOTOS

Measure:

Recommended excavator weight

15 – 25 t 35000 – 55000 lb
Max. Rated power

85 KW 115 hp (85 kW) hp
Max. Cutting depth (A)

705 mm 28 inch
Cutting wheel diameter (C)

800 | 2000 mm 31 | 79 in
Max. Cutting wheel diameter (C)

1800 mm 71 inch
Max. rpm

1100 rpm 1100 rpm
Recommended rpm

420 – 1000 rpm 420 – 1000 rpm
Recommended oil flow

55 – 130 l/min 15-34 gal/min
Max. operating pressure

350 bar 5080 psi (350 bar)
Torque at 350 bar

700 Nm 500 lbf.ft
Weight of drive unit, approx.

420 kg 926 lb
Weight of protective cover

90 |190 kg 198 | 419 lbs
Weight of cutting wheel

100 kg 220 lb
Total weight

610 | 710 kg 1345 | 1565 lbs
Standard hole pattern

LB20 LB20
Compatible rotation unit (KRM)

KRM30 KRM30
