KTR Chain Trenchers

Model KTR 130

TECHNICAL DATA
VIDEO
FOTOS
Measure:
  • Recommended excavator weight
    25 – 35 t 55,000 – 77,000 lb
  • Rated power
    130 kW 175 hp (130 kW)
  • Cutting width (A)
    200 – 450 mm 8 – 18 in
  • Cutting depth (B)
    1.000 – 1.500 mm 40 – 60 in
  • Recommended oil flow at 150 bar
    250 – 350 l/min 66 – 93 gal/min
  • Max. oil flow
    350 l/min 93 gal/min
  • Max. uniaxial compressive strength
    60 MPa 8,700
  • Weight
    3.700 kg 6,650 lb
  • Pick box
    PH 22 Type PH 22 Type
  • Standard pick
    ER 12/45/38/22 HC  ER 12/45/38/22 HC
