Model KR 65

TECHNICAL DATA

VIDEO

FOTOS

Measure:

Recommended excavator weight

12 – 18 t 25K – 40K lb
Rated power

65 kW 85 hp (65 kW)
Drum cutter length (A)

1195 mm 47 in
Cutting width (B)

805 mm 32 in
Cutter drum diameter (C)

587 mm 23 in
Recommended rpm

70 rpm 70 rpm
Recommended oil flow

145 l/min 38 gal/min
Max. oil flow

170 l/min 45 gal/min
Max. operating pressure

400 bar 5800 psi (400 bar)
Torque at 380 bar

12300 Nm 9050 lbf·ft
Cutting force at 380 bar

41.8 kN 9395 lbf
Max. rock compressive strength

60 MPa 8700 psi
Weight per cutting width

900 kg 1985 lbs
Pick box

PH 30 HD Type PH 30 HD Type
Number of picks

44 Pcs 44 Pcs
Standard pick

17/75/70/30 Q 17/75/70/30 Q
Standard hole pattern

LB20 LB20
Compatible rotation unit (KRM)

KRM40 KRM40
