KR range

Model KR 80

TECHNICAL DATA
VIDEO
FOTOS
Measure:
  • Recommended excavator weight
    15 – 25 t 33K – 55K lb
  • Rated power
    80 kW 107 hp (80 kW)
  • Drum cutter length (A)
    1.235 mm 48.50 in
  • Cutter head width (B)
    805 mm 31 in
  • Cutter drum diameter (C)
    587 mm 23 in
  • Max. torque at 380 bar
    15.200 Nm 11,300 lbf·ft
  • Max. cutting force at 380 bar
    52.870 N 11,900 lbf
  • Recommended rotation speed
    85 rpm 85 rpm
  • Recommended oil flow
    150 – 190 l/min 40 – 51 gal/min
  • Max. oil flow at 10 bar
    210 l/min 55 gal/min
  • Max. operating hydraulic pressure
    400 bar 5,800 psi (400 bar)
  • Weight
    1.070 kg 2,300 lb
  • Pick box
    PH 30 HD Type PH 30 HD Type
  • Number of picks
    44 Pcs 44 Pcs
  • Standard pick
     ER 17/75/70/30 Q  ER 17/75/70/30 Q
